| Quantity | Price | Stock |
|---|---|---|
| Starting at |
$26.98
/ea
|
Ships 3 to 5 Days
|
| Maximum Input Voltage Limits | 28 VAC, 35 VDC |
|---|---|
| Environmental Operation Range (Humidity) | 0 to 95% RH non-condensing |
| Environmental Temperature Range (350 mA @ any output voltage) | -40F to 149F (-40C to 65C) *for other ranges see datasheet |
| Environmental Storage Range | -40F to 176F (-40C to 80C) |
| Wiring | 4 wires, 16 to 22 gauge |
| Rectification | Half-Wave Rectified |
| Grounding | AC & DC Ground are Common |
| Recommended Input Voltage | 18 to 28 VAC, 24 VDC (15 VA) |
| Output Voltage | 5 to 24 VDC @ 350 mA |
Download Product Information:
