Conbraco 10-616-10 Hot Water Relief Valve 1-1/4" x 1-1/2" 50psi 3969000Btu

Conbraco 10-616-10 Hot Water Relief Valve 1-1/4" x 1-1/2" 50psi 3969000Btu
Images for general purposes only. Actual may be different than depicted.
Conbraco 10-616-10 Hot Water Relief Valve 1-1/4" x 1-1/2" 50psi 3969000Btu Conbraco 10-616-10 Bronze Hot Water Safety Relief Valve 50 PSIG

Conbraco 10-616-10 Hot Water Relief Valve 1-1/4" x 1-1/2" 50psi 3969000Btu

SKU: 10-616-10
Rating:
Quantity Price Stock
20
Usually Ships 1-2 Weeks
$560.49     /ea
20
0
$0.00
0
$0.00
0
10-616-10
Apollo Conbraco 10-616-10 is a Hot Water Safety Relief Valve with an Inlet FNPT size of 1-1/4" and 1-1/2" Outlet FNPT.  The valve set pressure is 50 PSIG and the certified pressure range is 15-160 PSIG.  Used for hot water heating boilers and hot water supply systems applications.


Conbraco 10-600 Series is a non-corrosive, extremely high capacity and has a diaphragm isolated spring chamber.  High-Capacity heating system valves with female inlet and standard or expanded female outlet. Elevated seat for drainage of water away from the Seat area. The entire pressure range is National Board capacity certified.  The 10-600 Series Valve protects hot water heating boilers and boiler systems from excessive water pressure due to the failure of controls to regulate BTU input.


ASME Section IV capacity certified bronze safety relief valve for protection of hot water heating boilers systems and similar equipment.





Connection Type Female NPT
Factory Set Pressure 50 PSIG
Certified Pressure Range 15-160 PSIG
Maximum Temperature 250 F
Seat Material Silicone
Body Material Bronze
